| Effect Freq. Response | 20 Hz - 20 kHz |
| Dynamic Range Reverb | >78 dB Delay: >84 dB |
| THD | <0.03% @ 1kHz, max. level |
| Analog Equalizer | Low, Mid, HI, +/-15 dB, 50 Hz- 700 Hz, 350 Hz - 5kHz, 2 kHz - 20 kHz |
| Input Channels | Elec. balanced x 2 (XLR type) Elec. balanced x 2 (TRS phone) |
| Input Nominal Level | -20/ +4 dBm, switchable |
| Input Impedance | 10k-ohms |
| Input Level Control | Rotary, continuous |
| Input Level Monitor | 8-segment LED |
| A/D Channels | 1 |
| A/D Sampling Freq. | 44.1 kHz |
| A/D Resolution | 16 bits |
| D/A Channels | 2 |
| D/A Sampling Freq. | 44.1 kHz |
| D/A Quantization | 16 bits |
| Output Channels | Elec. balanced x 2 (XLR type) Elec. balanced x 2 (TRS phone) |
| Output/ Nominal Leve | l -20/ +4 dBm, switchable |
| Output/ Impedance | 600 ohms |
| Presets (ROM) | 1 -30, 91-99 |
| User Memory (RAM) | 31-90 (Battery Backup) |
| MIDI Control | program change. Note number for pitch change programs. Bulk dump and load. |
| Front Panel Controls | Input Level, EQ (LO ,Mid Hi Freq and Level), Mix, EQ On/Off, Mono/Stereo |
| Front Panel Keys | User Memory, Parameter, Level, Initial Delay, 1ST Ref, EQ, Cursor Keys, 10-key pad, Clear, Store, Recall/ Enter, -, Mute, INT Param, Utility, Bypass |
| Front Panel Display | 16 char. x 2 line LCD 2-digit 7-segment LED |
| Dimensions | 480 x 90 x 343mm |
| Weight | 5.5kg (12.13 lbs.) |
